Spare parts of the power source6. 2. 6.
Fig 6.10 to Fig 6.13
Item Reference no. Designation
1 00629085 Gas fl ow rate safety device
2 9000629198 Water fl ow rate safety device
3 9000629220 Water level safety device
4 9000629189 Water temperature safety device
5 9000699063 Coolant fi lter housing with stainless fi lter element
6 9000699064 Sieve fi lter element (stainless)
7 9000629170 Pump 24 V
8 9000629174 Gas solenoid valve 24 Vdc
9 0028009100 Sequencer 1 module and Sequencer 2 module
10 0028019100 Rotation or wire feeding module
11 0028029300 Source module
12 0028069100 LVDS screen module
13 0028279100 Source adapter
14 0028229100 Pump / motor inductor interface
9000629204 Source 300 A
9000629140 Switch self-holding (with EMERGENCY STOP)
9000629221 Switch (without EMERGENCY STOP)
15 9000629172 Fan 24 V DC
16 9000629184 Printer
17 00530054 Fuse FU1 (4 A)
9000530520 Fuse 6.3A x 500Vac
9000590068 Thermal paper roll 57 x 50
64599807 Ground cable AVC 70 mm², 9 m long
75110071 Coolant
75501002 Pressure-reducing valve with fl owmeter argon France
71701418 Pressure-reducing valve with fl owmeter argon Export
71701421 Pressure-reducing valve with fl owmeter argon/hydrogen
18 0028039100 AVC/oscillation module
19 0028079100 Arc voltage measurement module
9000532004 Fuse 3 A for module 0028229100
0023000901 A manual torch adaptater
