THE ART OF WELDING
P6
74-92 PN-0509076 Rev. 16
Spare parts of the touchscreen6. 2. 8.
Fig 6.16
Position Reference no. Designation
1 0026119199 Touchscreen unit
2 9000623722 Touchscreen
3 9000623724 Screen SVGA LVDS 10.4’
4 9000623725 Backlight converter for the screen
5
9000623723 Touchscreen controller (old)
9000623790 Touchscreen controller (new 09/2013)
6 0028239100 Interconnection card for the screen
7 0026119121 Cable power source / touchscreen link
