Setting to work4.
Receipt of a P6 power source 4. 1.
The P6 power source is delivered in packaging consist-
ing of a box and protection, etc. This original packag-
ing must be kept and used each time the power
source is transported, in order to avoid damage.
When the power source is not in use, it must be
stored on a suitable support and protected against
impact damage (even when in its packaging).
In the package you will fi nd:
A remote control unit D2616, 6-axes version •
(Fig.4.1 – Item 1b (option).
A 9 m long earth cable (Fig.4.1 – item 2).•
A gas hose connector (3 hose connectors if the •
optional second gas has been ordered) (Fig.4.1 –
Item 3).
Fig. 4.1 - Accessories supplied with the power source P6
This user manual (Fig.4.1 - Item 4).•
A USB Key (Fig.4.1 – Item 5).•
The installation CD ROM (Fig.4.1 – Item 6).•
A RJ45 cross-coupled cable to connect the PC with •
the power source (Fig.4.1 – Item 7).
A adapter manual torch ref. 0023000901 (Fig.4.1 •
- Rep.8).
Pad set anti-slip (Fig.4.1 - Rep.9).•
If a PC is used you must use the RJ45 cable supplied with the power
source. Failure to use this cable may result in hazards for the user.
Polysoude declines to accept any liability unless the PC/Power sour-
ce connection is made with the RJ45 cable.
