Powerware 9330 - Page 114

9-- 10
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
The Output screen shows the phase-to-neutral voltage, phase current, and
frequency, being supplied by the UPS system, followed by the KVA, KW, and power
factor measurements.
SYSTEM OUTPUT
VA
VB VC
KVA KW PF
IA IB IC
***
*** *** ***
******
*** ******
FREQ
***
UNIT
Figure 9 ---13. System Output Meter Screen
The Bypass screen shows the phase-to-neutral voltage, and frequency of the
bypass source.
Freq
BYPASS
VA
VB VC
*** *** *** ***
UNIT
Figure 9 ---14. System Bypass Meter Screen
