2-- 28
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
13. Remove the top side panel mounting screw (tie/grounding bracket location in
F i g u r e s 2 --- 1 1 o r 2 --- 1 3 ) f r o m b o t h t h e O p t i o n a n d U P S c a b i n e t s .
14. Secure the back of Options cabinet to the back of the UPS cabinet with the
tie/grounding bracket. Secure the bracket with the side panel mounting
screws.
15. Proceed to paragraph 2.4.3.
16. Using retained hardware, reinstall shipping brackets previously removed t o
front and rear of Options cabinet with the angle facing outward.(see Figures
2 --- 1 2 o r 2 --- 1 4 ) .
17. Secure the front of Options cabinet to the front of the UPS cabinet with the
long flat grounding/mounting bracket from the installation kit (see Figures
2---12). Use hardware provided in the kit to secure the bracket.
18. Remove the top side panel mounting screw (tie/grounding bracket location in
F i g u r e 2 --- 1 2 o r 2 --- 1 4 ) f r o m b o t h t h e O p t i o n a n d U P S c a b i n e t s .
19. Secure the back of Options cabinet to the back of the UPS cabinet with the
tie/grounding bracket. Secure the bracket with the side panel mounting
screws.
20. Secure cabinets to floor with contractor supplied hardware.
21. Proceed to paragraph 2.4.3.
2.4.3 Installing Options Cabinet Internal and UPS Optional Remote
Battery Power Wiring
1. If not already removed, remove left front solid panel and right front vented
panel from the Powerware 9330 (10 kVA---20 kVA) UPS cabinet or left front
solid panel and front vented panels from the Powerware 9330 (25 kVA---40
kVA) UPS cabinet. Front panels are secured with magnetic latches and are
removed by pulling panels straight forward to disengage magnetic latches (see
F i g u r e 2 --- 1 o r 2 --- 5 ) .
2. Remove screws securing internal safety shield panels and remove panels to
gain access to input and output terminals.
NOTE: Remove UPS cabinet input, output, and remote battery input conduit landing
plate to punch conduit holes.
3. If wiring an optional remote battery system, proceed to step 4; otherwise
proceed to step 6.
CAUTION:
When sizing battery system, do not exceed internal battery charger
capabilities. Refer to Chapter 15 “Specifications”, for maximum battery charger
currents.
4. Route battery cables from the remote battery system to UPS Remote Battery
Terminal Block. Refer to Appendix A of this manual for wiring access
information.
