Powerware 9330 - Battery Type; Battery Installation; Installing Internal Batteries in the UPS Cabinet

3-- 2
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
3.2 Battery Type
The following battery types are supplied in the UPS C abinets and external Battery
Cabinets. When purchasing UPS Cabinets or external Battery Cabinets without
batteries, only the following types are recommended. U se of any other battery type
inside Powerware cabinets will void the product warranty. When replacing batteries
use the same manufactuer and part number originally supplied with the unit to
ensure correct harness fit and terminal landing.
Battery Manufacturer
CSB Battery
Technologies, I nc.
C&D
Technologies, I nc.
Sterling
Battery Model HR12120WFR UPS12-100FR HA28---106FR
Battery Quantity
10 kVA---20 kVA
25 kVA---40 kVA
24
48
24
48
24
48
3.3 Battery Installation
3.3.1 Installing Internal Batteries in the UPS Cabinet
If the UPS cabinet was ordered witho ut batteries, install the batteries in accordance
with the following procedure.
WARNING:
LETHAL VOLTAGE WILL BE PRESENT WHEN PERFORMING THE STEPS IN THIS SECTION.
1. Ensure that battery breaker CB2 is in the OFF position. If not, set breaker to
OFF position.
2. Remove left front solid panel and right front vented panel from Powerware 9330
(10 kVA---20 kVA) UPS or left front solid panel and front vented panels from
Powerware 9330 (25 kVA---40 kVA) UPS. Front panels are secured with
magnetic latches and are removed by pulling panels straight forward to
disengage magnetic latches.
3. Remove screws securing internal safety shield panels and remove panels to
gain access to battery trays.
4. Remove battery trays, containing wiring and nylon straps, from the UPS
cabinet.
5. Select batteries in a accordance with paragraph 3.2. Use batteries of the same
age, type, and manufacturer, in each string, so UPS performance is not
affected.
6. Install four batteries per tray and electrically interconnect the batteries in
a c c o r d a n c e w i t h F i g u r e 3 --- 1 o r 3 --- 2 .
7. Secure batteries to tray using nylon straps.
8. Reinstall battery trays into the UPS cabinet.
9. Connect battery strings in accordance with paragraph 3.4.1.
