Powerware 9330 - 6 Installing an Industrialrelay Card; Installation Procedures

6-- 1
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
Installing an Industrial
Relay Card
6.1 Installation Procedures
---As an option, an Industrial Relay Card (IRC) can be installed to indicate the
operating status of the UPS system using the customer’s monitoring equipment
and to connect an optional Remote Monitor Panel. The IRC uses normally open or
normally closed dry relay contacts to indicate the UPS status as listed in Table
6 --- 1 . F i g u r e 6 --- 1 s h o w s a n I R C .
PLUG-IN TERMINAL
FROM RELAY CONTACTS
CABLE EXIT
1/2” CONDUIT
OPENING FOR
BLOCK J2
TO CUSTOMER
MONITORING EQUIPMENT
F i g u r e 6 --- 1 . Industrial Relay Card (IRC)
6
