Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
Product Specifications
15.1 Model Numbers
The UPS systems are housed in freestanding, cabinets with safety shields behind
the front panels. The UPS systems are available in 50/60 Hz with various output
power ratings. Smaller models within a system may be upgraded in the field to
larger models:
System Models Nominal Frequency
Powerware 9330–20 10, 15, 20 kVA 50/60 Hz
Powerware 9330–40 25, 30, 35, 40 kVA 50/60 Hz
The following sections detail the input, output, environmental, and battery specifications for
the UPS.
15.2 UPS System Input
Operating Input
Voltage
(Nominal +10/-- 15%)
600 VAC for operation from 510 VAC to 660 VAC (50/60 Hz)
480 VAC for operation from 408 VAC to 528 VAC (50/60 Hz)
208 VAC for operation from 177 VAC to 229 VAC (50/60 Hz)
220 VAC for operation from 187 VAC to 242 VAC (50/60 Hz)
Operating Input
Frequency Range
3Hzofnominal(50Hzor60Hz)
Operating Input
Current
Refer to Appendix A, Tables A through F, for 10, 15, and 20 kVA
Models and Tables G through M, for 25, 30, 35, and 40 kVA
Models.
Reduced for Generator:
Adjustable
Battery Charge
Current
Battery Charge:
Up to 7 Amperes for 10, 15, and 20 kVA models
Up to 14 Amperes for 25, 30, 35, and 40 kVA models
Input Current
Harmonic Content
10% THD at full load (with input filter option installed)
30% THD at full load (without input filter option installed)
Power Factor Minimum 0.96
Line Surges 6 kV OC, 3 kA SC per ANSI 62.41 and IEC 801---4
Battery Voltage 288 VDC nominal
(144 cells @2V/cell)
