Typical Powerware 9330 (25 kVA---40 kVA) UPS System
System Configurations
These UPS system configurations are possible:
• Single Module UPS with integral battery
• Single Module UPS with integral battery and optional options cabinet
• Single Module UPS with integral battery and optional battery cabinet
• Single Module UPS with integral battery, optional battery cabinet, and optional
options cabinet
• Single Module UPS with remote battery
• Single Module UPS with remote battery and optional options cabinet
