Powerware 9330 - Page 243

A --- 6 9
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVI SION:
H
LOCATION OF OPTIONS CABINET TERMINALS
1of4
081502
OPTIONS CABINET POWER TERMINALS
POWERWARE 9330 (25 kVA-- 40 kVA)
164201300---11
MAINTENANCE BYPASS
SWITCH (MBS)
AC INPUT
BREAKER
BYP ASS
BREAKER
AC OUTPUT
BREAKER
TERMINALS
(USE SQUA RE---D TYPE
QO OR QOB BREAKERS)
OPTIONAL 42 CIRCUIT
DISTRIBUTION PANEL
