5-- 3
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
PLUG-IN TERMINAL
TO REMOTE MONITOR
CABLE EXIT
1/2” CONDUIT
OPENING FOR
BLOCK J1
OR PROVIDED
STRAIN RELIEF
Figure 5---2. Industrial Relay Card
CONDUIT AND WIRING SUPPLIED BY THE
CUSTOMER. THE MAXIMUM DISTANCE
BETWEEN THE REMOTE MONITOR AND
THE UPS IS NOT TO EXCEED 500 FEET.
PLUG-IN TERMINAL
TO REMOTE MONITOR
CARD
BLOCK J1
F i g u r e 5 --- 3 . R e m o t e M o n i t o r P a n e l ( R M P ) --- To p I n t e r n a l V i e w
