Installation Instructions
1.
Carefully slide the right drive housing cover over the crankarm. Reconnect the ASL
light input cable. Place the cover into position and use a 5/16" socket to reinstall the four
screw fasteners.
2.
Carefully slide the left drive housing cover over the crankarm. Place the cover into
position and use a 5/16" socket to reinstall the five screw fasteners.
3.
Reinstall the drive top cover . Position the top cover onto the housing and while apply-
ing light pressure first insert the top housing clips and then simultaneously inserting the
top cover front tabs into the front housing mounts and inserting the front clips into the
front housing brackets. Make sure the top cover clips are secure and install the two #3
Phillips screw fasteners.
Experience Series 800 Line EFX
64
5 Replacement Procedures
Covers and Panels Replacement
