Preen AFV+ Series - 5.3 Register Address Table

AFV
+
Series High Power Programmable AC Power Supply
5-93
5.3 Register Address Table
5.3.1 Write Register Addresses
Address (Hex)
Parameter Name
Notes
0001H
System Operation
Stop
Run General Mode
Run Step Mode
Run Gradual Mode
3Phase Independent
Setup
5-10- Reserved
11-31：Reserved
32-Reset
0002H
Remote/Local
Local
Remote
0003H
High/Low Level
Low Level
High Level
0004H-0029H
Reserved Addresses
System Settings：
0030H
U Phase Base Angle
Phase Angle Setup
(Optional )
0031H
Phase Angel between U-V
0032H
Phase Angel between U-W
0033H
Not available
0034H
Limit Current Value
Limit Current Value
(optional)
0035H-009fH
Reserved Addresses
General Mode：
0100H
General Mode Output Voltage
General Mode (3phase
synchronized)
0101H
General Mode Output
Frequency
0102H
U Phase Output Voltage
General Mode (3phase
Independent)
(Optional Feature)
0103H
V Phase Output Voltage
0104H
W Phase Output Voltage
