Preen AFV+ Series - Limit Current Setting; Phase Angle Control Setting (Optional); System Error Code Description; System Error Code

AFV
+
Series High Power Programmable AC Power Supply
5-102
5.5.10 Limit Current Setting
02 06 00 34 02 58 C8 AD(hex)
Note ： The limit current value here: Real Value x 10
5.5.11 Phase Angle Control Setting (Optional)
02 10 00 30 00 03 06 00 00 00 F0 00 78 E3 AD（hex）
Note: After setting the instruction phase angle value, all the application function
output voltage with the phase angle.
5.6 System Error Code Description
5.6.1 System Error Code
Description ： The following is the corresponding (uint 32bit) system error
information in system error status data.
bit
Fault Description
0
U-phase IGBT1 Over current fault
1
U-phase IGBT2 Over current fault
2
U-phase IGBT3 Over current fault
3
U-phase IGBT4 Over current fault
4
V-phase IGBT1 Over current fault
5
V-phase IGBT2 Over current fault
6
V-phase IGBT3 Over current fault
7
V-phase IGBT4 Over current fault
8
W-phase IGBT1 Over current fault
9
W-phase IGBT2 Over current fault
10
W-phase IGBT3 Over current fault
11
W-phase IGBT4 Over current fault
12
Heat sink is over-temperature
13
Transformer is over-temperature
14
Emergency Stop
