Preen AFV+ Series - 1.2 Key Features

AFV
+
Series High Power Programmable AC Power Supply
1-2
1.2 Key Features
A. Configuration
1. Local operation via the touch screen on the front panel.
2. Remote control via RS-485/RS-422/RS-232 or optional Ethernet/GPIB.
3. Protection for OVP, OCP, OPP, OTP and Vin LVP.
B. Input / Output
1. Selective output voltage range with high range 0-310V or low range 0-155V.
2. Input voltage is 380V±15% and customized input voltage is available.
3. Output voltage 0-310V
AC
4. Output frequency A version: 45-500Hz, B version: 45-120Hz and optional C
version: 300-840Hz.
5. Precise Meter Measurement
 Single phase output: V/F/I/VA/W/PF
 Three phase output: V
(L-N)
/I
(L-N)
/P
(L-N)
/VA/W/PF/Σ of three phases (for
three-phase balanced only)
6. Output frequency 45-120Hz characteristic chart
Figure 1.2 Output voltage and current characteristic chart
