AFV
+
Series High Power Programmable AC Power Supply
3-58
3.6 PGM Page
User can press at the MAIN page or press at the MENU page to enter
into METER page.
Figure 3.31 Item PGM. at MAIN page (left) and at MENU page (right).
Figure 3.32 PGM. setting page
The descriptions for the items and icons in the above figure are given as follows.
RAMP：User can set the start and end output voltage/frequency, dwell time of
ramp Set. The number of Ramp Set is up to 12 sets. The numbers of times the entire
sets can be repeated are 1-255.
STEP：User can set output voltage/frequency, dwell time of step Set. The
number of Step Set is up to 24 sets. The numbers of times the entire sets can be
repeated are 1-255.
The minimum time unit is 1 second. When set to 0 second, the system will
automatically change to 1 second.
