Preen AFV+ Series - 2.4 Input Connection

AFV
+
Series High Power Programmable AC Power Supply
2-29
2.4 Input Connection
For input connection, please open the front chassis door and remove the button
front panel of the product enclosure which is fixed via screws, then you will find the
input terminal as the Figure 2.10 below. The input power cord must be rated at least
for 85C. The input power cord must have rated current which is greater than or
equal to the maximum input rated current of the product.
Refer to Figure 2.10 and follow the below procedures step by step:
1. Open the front chassis door.
2. Remove the button front panel.
3. Remove the safety cover on the input terminal and screw the power cord tightly to
the input terminals of the product as follows,
3.1 Connect the Ground wire to the terminal “G” of the input terminals;
3.2 Connect the A cable wire to the terminal “R” of the input terminals;
3.3 Connect the B cable wire to the terminal “S” of the input terminals;
3.4 Connect the C cable wire to the terminal “T” of the input terminals.
4. Slip the safety cover over the input terminals.
Notice:
Three Phase also known as A / B / C or U / V / W or R / S / T or L1 / L2 / L3.
In different countries there will be different colors represent three phase cable and
please find the information below for reference.
USA : A (Black) / B (Red) / C (Blue) / N (White or Gray) / G (Green or Green with
Yellow Stripe)
EU : A(Brown) / B(Black) / C(Gray) / N(Blue) / G(Green)
China : A(Yellow) / B(Green) / C(Red) / N(Blue) / G(Green with Yellow Stripe)
Taiwan : A(Red) / B(White) / C(Black or Blue) / N(White) / G(Green with Yellow
Stripe)
