Preen AFV+ Series - Page 21

AFV
+
Series High Power Programmable AC Power Supply
1-9
Frequency
Resolution
0.01Hz
Frequency
Accuracy
±0.02% F.S.
Current Range
(RMS)
0 -
416.7A
0 -
555.6A
0 -
833.3A
0 -
1111.1A
0 -
1388.9A
0 -
1666.7A
0 -
2222.2A
0 -
2777.8A
0 -
3333.3A
0 -
4166.7A
0
-5555.6A
Current
Resolution(RMS)
0.1A
Current Accuracy
(RMS)
0.5% F.S.+4 counts
Power Range
0 -
150kW
0 -
200kW
0 -
300kW
0 -
400kW
0 -
500kW
0 -
600kW
0 -
800kW
0
-1000kW
0 -
1200kW
0 -
1500kW
0 -
2000kW
Power Resolution
0.1kW
Power Accuracy
1% F.S.+6 counts
GENERAL
Efficiency
≥85% at Max. Power
HMI
Touch Screen, 7" Color TFT LCD
Program Mode
STEP : 24 sets / 255 cycles. (Volt./Freq./Time)
RAMP : 12 sets / 255 cycles. (Volt./Freq./Time)
Soft Start
Setting : Rated Volt. / Rated Freq. / Start Volt. / Start Freq. / Delay Time / Ramp Time
Three Phase
Independent
Adjustment
U-N/V-N/W-N, Adjustment 0-310V
Protection
Input : Input N.F.B, Over Voltage, Under Voltage,
Output : Over Voltage, Over Current, Reverse Current, Over Temperature
and machine will display the error code and give a warning sound.
Remote Interface
Standard : RS-232/RS-422/RS-485 Option : GPIB, Ethernet
Operational
Temperature
0℃ ~45℃
Humidity
0~90% ( Non condensing )
Altitude
< 1,500m
Dimensions (H x W
x D) *5
1900 * 1178 *
1200 mm
2050x 3881 x 1539
mm
2050 x 4716 x
1520 mm
2050 x 6003 x
1520 mm
2200 x
10827
x1590
mm
2200 x 12990 x
1590 mm
Weight *5
1835kg
2415kg
3620kg
4670kg
5820kg
7720kg
9240kg
11080kg
16800kg
18720kg
19950kg
*1 Please contact for other voltage specification.
*2 The rated input voltage is 380V.
*3 For type A (45-500Hz) and output power 20kVA and over models, the output power will be
influenced by the frequency characteristic curve.
*4 Low : 90 - 140V or High 180 - 280V.
*5 For 300kVA models and over, please contact us for details
* All specification are subject to change without notice.
Table 1.3 Technical Specifications (three-phase model /150kVA~2000kVA)
