Prontonet User’s Manual v410 109
Communications Ports
LAN port
 10/100 Base-T Ethernet.
 Connector type: RJ-45
GPIO Port
 11 TTL inputs and outputs.
 Inputs: Closure to ground.
 Outputs: Open collector. 40 mA Max o 40 VDC max.
RS232 Port
 RS232 bi-directional asynchronous
 Supports data rates to 38.4 Kbps.
 Connector Type: DB9F
X21 Port
 Serial Synchronous interface.
 Bit rates: 64, 128, 192, 256, 384 Kbps.
VI.3 Power Supply
Main
 Universal power Supply
 Operating Voltage: 94-250 V
 Operating Line frequency: 47-65 Hz.
 Out Power : 25W
Secondary (Optional)
 Nominal input: 24 VDC.
 Input range: 18..36 VDC.
 Power: 25 W.
