Prontonet User’s Manual v410 65
V.1.3 System Configuration
Grouped here are functions that affect the general operation of the unit.
Loop: This sets up an Encoder-Decoder loop. Its purpose is to help the user
to find problems with audio connections. The loop takes place in accordance
with the configuration available at that moment.
PLL: This is a special option that allows you to select the PLL reference clock
when NET = IP.
Backup: Backup configuration. The ProntoNet allows to use the ISDN line as
a backup when the unit works in IP or X21 mode.
The backup is enabled by clicking the “Backup” box.
For more information about the backup operation see chapter IV (CONF –
SYS – BACKUP) and Chapter VI – How the backup Works?
Redial:It is possible to configure a number of redials. The ProntoNet will try
the connection in the following cases:
1.- The unit is trying the connection for the first time.
2.- The unit was connected and lost the connection because the line
dropped or the line was disconnected from the other end.
Keypad: This option allows the user to lock automatically the frontal panel
keypad. Automatic means that the keypad is locked a short while (around 1
minute) after you just press a key. It is possible to unlock from the keypad by
pressing Ok and then *. This option is available from version 3.3.1.
Monitor: This option allows the user to hide or display additional information
on the main window:
- Vumeters: Indicates audio levels.
