Prontonet User’s Manual v410 62
V.1.1.6. GPIO Port:
From this option the inputs and outputs of the GPIO port are configured.
INPUTS
Transparent Under this configuration, the state of the input will be present in
its homologous output in the ProntoNet connected in the other
end.
Connect Line 1 When this input is activated, the ProntoNet will proceed
automatically to connect the line 1.
Disconnect Line 1 When this input is activated, the ProntoNet will proceed
automatically to disconnect the line 1.
Connect Line 2 When this input is activated, the ProntoNet will proceed
automatically to connect the line 2. It makes sense only when the
ProntoNet is working in ISDN mode as a DUAL CODEC.
Disconnect Line 2 When this input is activated, the ProntoNet will proceed
automatically to disconnect the line 2. It makes sense only when
the ProntoNet is working in ISDN mode as a DUAL CODEC.
Mute Left When this input is activated, the left audio output will be muted.
Mute Right When this input is activated, the right audio output will be muted.
Acknowledge alarms When this input is activated, the alarms will be acknowledged.
The inputs are activated by grounding
Transparent configuration only works with audio algorithms that support
ancillary data and have been previously activated.
