Prodys ProntoNet - III.2.2.5. Screen 5: LAN Port Configuration Parameters; III.2.2.6. Screen 6: General Configuration; III.2.2.7. Screen 7: GPIO

Prontonet User’s Manual v410 27
ADDR:192.168.100.100
MASK:255.255.255.000
CODEC IP
AUDIO IN: ANALOG
CODEC ISDN
AUDIO IN: DIG - EXT
GPI:0000
GPO:1010
If the Encoder is configured to automatic mode or if the Decoder is not
synchronised you will see the following:
III.2.2.5. Screen 5: LAN port configuration parameters
Here we see the IP address and mask.
III.2.2.6. Screen 6: General configuration
This shows the NET type and the audio input selected. Here are two such
examples:
a) NET = IP and analog audio input:
b) NET = ISDN and digital audio input with external sync:
III.2.2.7. Screen 7: GPIO
This represents the GPIO status:
E1:AUTO
E2:NOT AVAILABLE
