Prontonet User’s Manual v410 33
SET ENCODER 1 >>
{MPL2}MPL3 AAC2LC
MPEG SET BIT RATE
{64}128 192 256 384
MPEG SET MODE
{MONO}JS STER DUAL
MPEG SET Fs
{48}32 24
MPEG SET CRC
ON {OFF}
MPEG SET AUXDATA
ON {OFF}
IV.4.5 MPEG Layer II:
The configuration steps are:
1. Bit rate.
2. Mode: MONO, JOINT STEREO, STEREO or DUAL.
3. Sample rate: 48, 32 or 24 KHz.
4. CRC validation on/off
5. Auxilliary data on/off
NOTICE – MPEG Layer II RESTRICTIONS
 If NET = ISDN Bit Rate > 128 Kbps is not possible.
 If the Bit rate > 128 Kbps a 24 Khz sample rate is not possible.
 If the Bit Rate > 192 Kbps MONO mode is not possible.
