In the PERFORMANCE PARAMETERS field, prioritize data transmission in certain directions.
Parameter Description
CAN RECEIVE LOOPS
PER CYCLE
Input field for prioritizing CAN reception.
WIRELESS RECEIVE
LOOPS PER CYCLE
Input field for prioritizing WLAN / Bluetooth reception.
Performance Parameters field
In the POWER MANAGEMENT SETTINGS field, define the parameters for the sleep function. When
sleep function is enabled, the CANlink wireless goes into sleep mode after clamp 15 is switched
off. The CANlink wireless is put into operating mode via clamp 15 or a CAN message.
Parameter Description
ENABLE ACTIVE SLEEP
AND CLAMP
15 WAKEUP
Enable/disable sleep function.
IME UNTIL SLEEP AFTER
CLAMP 15 REMOVAL
Input field for the time after which the CANlink wireless goes into
sleep mode due to a status change of clamp 15 to low. Enter the
time in seconds.
Power Management Settings field
In the SDO SERVER SETTINGS field, define the parameters for the SDO server.
Parameter Description
ERVER TIMEOUT
Input field for time.
SERVER
Input field for the COB-ID. Default value: 0x600
SERVER
Input field for the COB-ID. Default value: 0x580
SERVER
Input field for the COB-ID. Default value: 0x600
TX COB-ID (SERVER 2)
Input field for the COB-ID. Default value: 0x580
HEXADECIMAL
DECIMAL
Toggle between hexadecimal and decimal display.
OAD DEFAULTS
Load default SDO server settings.
SDO Server Settings
NOTICE
When the COB IDs are set to the default values, the device's node ID is automatically added
according to the CANopen specification. If other values are defined, they are directly used
without adding the device's node ID.
