ProMinent gamma XL User Manual

A time event lets you trigger an action precisely to
the minute.
If the action is to be triggered precisely to the
second, then you need to set up your programming
on a delayer.
11.3.2.1.4 Delayer
A delayer lets you delay an action with regard to a time event
(trigger).
Delayers can be both time events and also actions.
No. Time event (trigger) Action
01 Config I/O 1 close Start Delayer 1 -
02 Config I/O 1 close Start Delayer 2 -
03 Config I/O 1 close Start Delayer 3 -
04 Init - Halt -
05 Delayer 1 after 60 sec Config I/O 2 close
06 Delayer 2 after 120 sec Manual 100
strokes /
min, 60 %
stroke
length
07 Delayer 3 after 180 sec Halt -
08 Delayer 3 after 180 sec Config I/O 2 open
The example means:
A flank at
‘Config I/O 1’ means that ...: :
n after 60 s output
‘Config I/O 2’ is closed,
n after a further 60 s, the pump pumps in
‘Manual’ operating
mode at 100 strokes / min and 60% stroke length,
n stops after a further 60 s and output
‘Config I/O 2’ opens
again.
Example of a program
A program line with a time event
‘Delayer’ X thus also includes the
element ‘Delay time’ .
The ‘Delay time’ specifies by which time the start of the selected
action is to be delayed (1 s ... 9,999 s = approx. 2 h 45 min).
The delayer itself must first have been called up by a time event as
an action. You can use 15 different delayers.
–
With the time event ‘Delayer’ X, you can
trigger an action precisely to the second.
– The clock of the gamma/ XL has an accuracy
of ±1 s/24 h.
Set up / ‘Menu’
84
