11.3.2.1.5 Inputs
A 0/1 contact signal, for example at pin 1 of the
‘Config I/O’
socket
can be a triggering event.
Time events (triggers) Action
Config I/O 1 Relay 2 open
The example means:
If a 0/1 contact signal is closed between pin 1 of the
‘Config I/O’
socket and pin 4, then the
‘Relay 2’
should switch to
‘open’
status.
Example
11.3.2.1.6 Outputs
The timer can output a 1/0 contact signal e.g. between pin 3 of the
‘Config I/O’
socket and pin 4.
Time events (triggers) Action
Cycle Switching time
Workdays 1 (Mo-Fr) Time of day 12:00 Config I/O 3
The example means:
At 12:00 on workdays, the timer outputs a 1/0 contact signal
between pin 3 of the
‘Config I/O’
socket and pin 4
Example
11.3.2.2 1 time event - several actions
You can assign 1 time event to several actions. To do so, always
use the same cycle and the same switching time! :
No. Time event (trigger) Action
01 Workdays 1 (Mo-Fr) Time of day
12:00
Halt -
02 Workdays 1 (Mo-Fr) Time of day
12:00
Batch (input) 50 strokes
03 Workdays 1 (Mo-Fr) Time of day
12:00
Relay 1 -closed
04 - - ... .
Example
Set up /
‘Menu’
85
