RLX2 Industrial Hotspot Series
Page 144 of 212 ProSoft Technology, Inc.
June 15, 2015
This is the version of the firmware image that the radio
is currently running. It can be primary or secondary.
Each radio has two copies of operating firmware
installed, and the radio will automatically transition from
one to the other if one of them becomes corrupted.
Firmware images in the radio can be either compressed or
uncompressed.
The Ethernet status is Attached for a radio connected to a
wired Ethernet network, otherwise Detached.
The operating channel and channel width. The width value
will always be 20MHz except on 802.11n devices where it
can be 20MHz or 40MHz. Example: 48, 20 for channel 48
with a 20 MHz channel width.
This indicates the encryption setting for the radio. Valid
setting are WPA/WPA2-AES; WPA/WPA2-TKIP;
WPA/WPA2-AES&TKIP; WPA-TKIP+WEP128;
WEP128; WEP64; and none.
This is the number of times the IH Browser has
unsuccessfully attempted to contact the device. Ideally this
number should always be zero.
This is the setting for RSTP in the radio. Allowed states are
Enabled, Disabled, and STP. The STP state is a legacy “non-
rapid” Spanning Tree option. All radios on a network must
have the same RSTP state to link properly.
The link time of the device, for example 24d,13h,10m, 32s.
This is the current effective data rate of the device. This may
be slower than the configured nominal rate because of
retries or other environmental factors. For 802.11a/b/g
devices, the data rate is expressed in kilobits or megabits per
second (e.g. 54Mb/s.) For 802.11n devices, the data is
expressed in MCS rates from 0 to 31 (e.g. MCS16.)
The internal temperature of the radio as measured on the
circuit board in degrees Celsius. Note that internal
measured temperature may in some cases exceed ambient
temperature rating.
This value is the percentage of packets transmitted
more than once during the last five-second interval.
The amount of time the device has been running since the
last power cycle or reset. For example 1d,4h,13m,25s.
The type of RLX2 radio. The values can be RLX2-IHA, RLX2-
IHG, RLX2-IHFN, or RLX2-IHW.
