5-17
ROTALIGN 01.2000
Flange-mounted horizontal machines
7) MOVE to eliminate offset
Press the softkey marked "MOVE" to start the offset correction
function. Rotate the shafts such that the sensors are located at bolt
position number 1 (the top position for horizontal shafts; see step 4
above), then press the "START" softkey to begin lateral positioning
for correction of offset.
Do not loosen the machine anchor bolts until
after START has been
pressed! Move the machine laterally while viewing the screen; note
the order of the bolts for correct orientation (refer to step 4 above if
necessary). Jack bolts or other mechanical or hydraulic adjustment
methods are recommended for best results.
The Average function, set in the XY VIEW screen is automatically
used during Move measurements. With this option, you can set the
number of measurements (up to 2048) to be taken and averaged
during readjustment, see page 4-44.
Tighten down the anchor bolts, then press STOP to conclude the
horizontal alignment procedure.
8) Final check
Press the "M" key to take a final set of readings in order to confirm
proper alignment.
Remember :
Remove the components from the shaft before switching on the
machine!
START
MOVE
STOP
WARNING!
