ROTALIGN 01.2000
Compact and lightweight, this bracket is designed to provide ex-
tremely rigid support for the measurement components with a
minimum of mounting time and effort. The compact chain-type
bracket fits onto shafts and couplings ranging from 15 to 500 mm (1/
2" to 20") in diameter. Longer chains are also available. Mounting
instructions on page 4-11.
Other accessories
See page 6-15 for a list of popular ROTALIGN accessories.
The ROTALIGN product catalog illustrates and describes some
additional accessories available for ROTALIGN. It is available under
order number ALI 9.300.
Among the most useful accessories are the various brackets specially
designed for mounting ROTALIGN on specific machine configura-
tions. These are described in detail in the appendix to this manual
(page 6-18).
Compact chain-type bracket ALI 2.891 set
ROTALIGN components
