2-3
ROTALIGN 01.2000
The ROTALIGN Computer ALI 3.550
ON
OFF
CLR
DIM
M
EN
U
M
0
3
8
4
1
2
7
9
5
6
E
N
T
E
R
E
N
T
E
R
M
A
I
N
A
U
X
...
..B
A
T
T
.....
.
.
...
..
.
..
.....
.
.....BATT ..... ........ ........
C
H
A
R
G
E
S
L
E
E
P
The heart of the ROTALIGN system is the ROTALIGN computer, built
to rugged industrial standards of shock and water resistance. It
contains a complete desktop computer with LCD display and numer-
ic-function keypad. Names and letters can be entered where neces-
sary with a special on-screen character table.
Measurement data pass directly via cable (or IR link, see page 6-23)
from the receiver to the ROTALIGN computer and are then used to
calculate the alignment diagram. Numerous software functions allow
the computer to handle a wide range of alignment situations.
Notes on ROTALIGN operation
To ensure proper and safe operation of the ROTALIGN system, there
are a few operating rules which must be observed:
- The ROTALIGN must not be operated with the housing open or
removed.
- Only original spare parts and accessories must be used.
- The ROTALIGN must only be operated by trained personnel.
- Any unauthorized modifications to the ROTALIGN and its compo-
nents shall render all warranty coverage null and void.
- When using the ROTALIGN laser, adhere to all safety information
regarding its safe operation (see page 1-7).
The ROTALIGN computer
