2-2
ROTALIGN 01.2000
ROTALIGN overview
The ROTALIGN system mounted across a machine coupling
The ROTALIGN laser alignment system:
BRACKETS used to mount the laser and receiver securely on the
shaft on either side of the machine coupling*.
LASER fitted to the machine shaft on one side of the machine
coupling, shines a beam across the coupling*. The
beam has no sag and is extremely straight.
RECEIVER fitted to the shaft on the other side of the coupling*;
contains two sensors to detect the precise position and
angle of the incident laser beam.
COMPUTER connects to the receiver; calculates the machine align-
ment from data collected from the receiver during
shaft rotation. The machines can then be aligned with
aid of a "live" graphical display. The ROTALIGN
computer can also be connected to a PC with the
ROTALIGN Commander software (page 6-16).
*The laser and receiver can be mounted on the coupling or on the
inside faces of the coupling when the spacer element is removed.
ROTALIGN
Computer
Compact
chain-type
bracket
Receiver
Laser
12
3
6
9
O
N
O
F
F
C
L
R
D
IM
M
ENU
M
0
3
8
4
1
2
7
9
5
6
E
N
T
E
R
E
N
T
E
R
M
A
I
N
A
U
X
.
.
.
.
.
B
A
T
T
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.....BATT ..... ........ ........
C
H
A
R
G
E
S
L
E
E
P
ROTALIGN overview
