6-15
ROTALIGN 01.2000
ROTALIGN accessories
ROTALIGN accessories
ROTALIGN accessories
ALI 3.572 Lead-acid rechargeable block battery
(MAIN BATT) (see page 6-17)
ALI 3.576 110V/220V Mains adapter/charger
(see page 6-17)
ALI 3.581-5 ROTALIGN Receiver cable 5 m
ALI 3.579 ROTALIGN Beam Deflector
ALI 3.606 Receiver dust cap
ALI 3.607 Laser dust cap
ALI 3.573 Computer stand
ALI 3.574 2 Thumbscrews for computer stand
The stand angles the computer on a table at a
convenient reading position, or lets it hang from a
pipe etc.
DEMO-FIX ROTALIGN Compact Demonstration Stand
ALI 3.595 ROTALIGN Case (aluminium), complete
ALI 3.591set ROTALIGN COMMANDER 2, see next page
ALI 3.591uset ROTALIGN COMMANDER 2 upgrade
ALI 3.471 ROTALIGN Upgrade Package
ROTALIGN infrared interface, see page 6-23 for details.
Accessory mounting brackets, bracket parts
(see following pages and the Laser Alignment System product
catalog ALI 9.300 available free of charge.)
ALI 2.230 Magnetic sliding bracket, individual
ALI 2.109set Extra-thin bracket, two pairs in different sizes
ALI 2.112set Compact magnetic bracket, set of 2
ALI 2.106set Coupling bolt hole bracket, set of 2
ALI 2.114 300 mm chain for ALI 2.891 bracket
ALI 2.115 600 mm chain for ALI 2.891 bracket
ALI 2.116 1500 mm chain for ALI 2.891 bracket
ALI 2.117 Bracket frame (ALI 2.891) & Allen wrench
Support posts, 4 pieces each, with colored end caps:
ALI 2.170 115 mm / 4 ½”, white
ALI 2.171 150 mm / 5 15/16", black
ALI 2.172 200 mm / 7 7/8", grey
ALI 2.173 250 mm / 9 7/8", green ALI 2.173
ALI 2.174 300 mm / 11 13/16", yellow
0 0593 0054 Storage pouch
