PRÜFTECHNIK ROTALIGN ALI 3.500 User Manual

6-31
ROTALIGN 01.2000
Sample ROTALIGN Report
ROTALIGN / V 2.00 J / ID92311491 / 0
Horizontal machine alignment 3.6.1996 17:37
===================================
ACHEMA H 3.6.96 17:37 PAGE 2
===================================
**** THERM. GROWTH RIGHT MACHINE
Front foot (vertical) 0 (mm)
Back foot (vertical) 0 (mm)
Front foot (horizontal) 0 (mm)
Back foot (horizontal) 0 (mm)
**** MEASUREMENT MODE CONTINUOUS SWEEP
**** MEASURED VALUES AT COUPLING
gap (vertical) -0.47(mm)
offset (vertical) -0.36(mm)
gap (horizontal) 0.45 (mm)
offset (horizontal) -0.73(mm)
**** SUMMARY OF VALUES AT COUPLING
gap (vertical) -0.47(mm)
offset (vertical) 0.36 (mm)
gap (horizontal) 0.45 (mm)
offset (horizontal) -0.73(mm)
**** REQUIRED FOOT CORRECTIONS LEFT MACHINE
NONE
**** REQUIRED FOOT CORRECTIONS RIGHT MACHINE
Front foot (vertical) 0.6 (mm)
Back foot (vertical) 1.54 (mm)
Front foot (horizontal) -0.96(mm)
Back foot (horizontal) -1.86(mm)
**** TOLERANCE MAXIMUM CPLG VALUES
gap 0.5 (mm)
offset 0.5 (mm)
