PRÜFTECHNIK ROTALIGN ALI 3.500 User Manual

4-42
ROTALIGN 01.2000
The "clock" shows which points are
still valid after deactivation
Point deactivated!
CENTERED!
Circle shows
deactivated
point
As shown below, the deactivated point is indicated by a white circle:
Horizontal machine alignment - measurement
Press the CLR key to delete all current measurement values. Although
this clears the measurement values from memory, thereby speeding
up transitions between options in measure mode, the measured
results remain visible in the Measure screen. They may also be
viewed in the Results and Table screens.
