-102-
COMMON
Electrical connection – Observe Local and National Codes!
Connected voltage L1 – L2 Volt
L1 – L3 Volt
L2 – L3 Volt
L1 - N Volt
L2 - N Volt
L3 - N Volt
N - Ground Volt
YES NO
Ground connection to mains distribution panel?
IMPORTANT!!
Does indicated voltage on the unit data correspond
with the measured voltage?
3 phase breaker installed?
Breaker accessible from front by operator?
Breaker size / Fuse rating A
Nominal Amp draw per phase Electric units A
3AC 3AC 3AC 3(N)AC 3NAC 3AC
200V 230V 240V 400V 415V 440V
6 x 1/1 24 25 24 14,5 14,5 13
6 x 2/1 53,5 53 51 30,5 31,5 28
10 x 1/1 48 48 46 27,5 28,5 25
10 x 2/1 100 93 89 53,5 56,5 49
20 x 1/1 100 93 90,5 53,5 56,5 49
20 x 2/1 166 156 149 89,5 92,5 81,5
Measured amps per phase A
Nominal Amp draw per phase Gas units
1NAC 2AC 1NAC
100V 200V 230V(240V)
6 x 1/1 3 1,5 1,3
6 x 2/1 3,5 1,8 1,5
10 x 1/1 3,5 1,8 1,5
10 x 2/1 4,5 2,3 2
20 x 2/1 7 4 3,5
20 x 2/1 10 5 4,4
Measured amps per phase A
