Rational SCC Line User Manual

-22-
S
C
M
Function Connection
I/O PCB
Cabinet
Display
Time
Display
Comment
F1 Steam 50%, Electric unit X24:(1-2) actual temp.
B5 steam gene-
rator
1 / 0 Gas:
no function
F2 Steam 100%, Electric unit X24:(1-2)+(5-6) actual temp.
B5 steam gene-
rator
1 / 0 Gas:
no function
F3 Hot Air 50%, Electric unit X24:(7-8) actual temp.
B1 cabinet
1 / 0 Gas:
no function
F4 Hot Air 100%, Electric unit X24:(7-8)+(3-4) actual temp.
B1 cabinet
1 / 0 Gas:
no function
F5 Steam, Gas unit BUS actual temp.
B5 steam
generator
1 / 0 Electric:
no function
F6 Hot Air Top, Gas unit BUS actual temp.
B1 cabinet
1 / 0 Electric:
no function
F7 Hot Air Bottom, Gas unit BUS actual temp.
B1 cabinet
1 / 0 Electric:
no function
F8 Bottom Motor MAX speed BUS Set rpm Act. rpm
F9 Bottom Motor MIN speed BUS Set rpm Act. rpm
F10 Top Motor MAX speed BUS Set rpm Act. rpm
F11 Top Motor MIN speed BUS Set rpm Act. rpm
F12 Solenoid valve quenching X19:(2-4) actual temp.
B2 quenching
Y2
1 / 0
F13 Solenoid valve fi lling X19:(1-3) Level electrode
S2, 1 / 0
Y1
1 / 0
F14 Steam generator pump X18:(1-2) M4
X12:(1-4) S2
Level electrode
S2, 1 / 0
M4
1 / 0
F15 Buzzer 1 / 0
F16 All Displays / LED
F17 Relais Vent hood
UltraVent
(door open/close)
X 23: (1-2-3) 1 / 0
F18 no function
Service level: F -- Function test
NOTE: In Function test components are NOT protected against overload!
