Rational SCC Line User Manual

-68-
S
S
C
C
Diagnostic
Diagnose
Running Times
Laufzeiten
Basic Settings
Grundeinstellungen
Function Test
Funktionstest
5 - Function Test
Fan Motor top START
Speed 4
1800 rpm
Actual Speed
1800 rpm
19 Display lights
20 Exhaust hood
21 Sicotronic
1
2
3
4
1
2
3
4
Function Test
1 Steam (Dampf) 50%
(Gas - not used)
2 Steam (Dampf) 100%
(Gas - Dampf Burner)
3 Hot Air 50%
(Gas - Burner top)
4 Hot Air 100%
(Gas - Burner bottom)
5 Fan motor top
6 Fan motor bottom
7 Solenoid valve fi llling Y1
8 SC Pump M4
9 Solenoid quenching Y2
10 Solenoid Moistening Y3
11 Humidity fl ap motor M3
12 CleanJet Pump M6
13 Drain Valve Motor M7
14 Gas Steam Blower
15 Gas Hot Air Blower Top
16 Gas Hot Air Blower bottom
17 Buzzer T2
18 Interior Light H1
Overview Function test
