Rational SCC Line User Manual

-58-
S
S
C
C
15 - DIAGNOSTIC
Clima
P1 - B4 - RPM
Default out
0,48V 2,24V
B4 85% rpm
145°C 1850
Default: 0,4-0,55V
At standard speed:
Out ca. 1,3 - 1,6V Combi 200°C
(392°F)
Out ca. 1,5 - 1,9V Steam 100°C
(212°F)
Out ca. 2.5 - 3,0V Hot air 60°C
(140°F)
18 - DIAGNOSTIC
Hot Air
0% 50% 100%
21 - DIAGNOSTIC
Volume
Calc 3,6l
check
Fill Norm
3,2l 4,2l
Window 3: Release volume
Window 4, left side:
Filling volume during last SC-Auto-
matic. As of SW version 01-07-04
the fi lling progress can be observed.
Window 4, right side: nominal fi lling
volume with a clean steam tank
16 - DIAGNOSTIC
Clima Status
Cal speed1 Error
xxxrpm --------
Dry Wet Combi
xxxx xxxx xxxx
- Display of calibration values rela-
tive to the different motor speeds
and unit size;
- Normal values between
72000-110000
19 - DIAGNOSTIC
Steam
0% 50% 100%
22 - DIAGNOSTIC
M6 CleanJet Pump
Y2 Quenching solenoid
M6 0-1
Y2 0-1
As of SW Version 01-07-04
service mode can be selected
while CleanJet mode is active.
17 - DIAGNOSTIC
Clima Motor
M3 1-0
S4 0-1
No steam production,
when S4 is „0“ => open!
20 - DIAGNOSTIC
SC-Automatic
53min
45sec 60min
Window 3:
- 53min since last SC -automatic
- Pressing Test => time will be set
to set time plus 1 minute
Window 4:
- 45sec: Preset SC-duration (20-90sec)
- 60min: Preset SC-time (20-90min)
23 - DIAGNOSTIC
M7 Drain valve motor
S12 micro switch
M7 0-1
S12 1-0
As of SW Version 01-07-04
service mode can be selected
while CleanJet mode is active.
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
Test
SCC Diagnostic Mode
