Fault List CM
Indication "E13" (SC-automatic)
Unit shows E13
Activate function test
Level electrode of the steam
generator did not recognise a
reduction of the water level during
last SC-Automatic
INFO
Select step F14
SC Pump M4
by pressing timer key,
activate function with
core temper. key
Is pump active and
water is pumped out?
Short circuit level electrode or
check drain system and
quenching box for dirt
clean if necessary
Yes
230V output at connector X18
1/2 during function test
present?
Fuse F2 of pcb ok?
Change fuse,
check cable and pump
for short circuit
Change pcb
No
Check pump for scale
deposits or other dirt,
that blocks the impeller
Clean housing of the pump,
descale steam generator
and /or change pump
No
Yes
Check cable, connector
and pump.
Change faulty part.
Yes
Aux. contact 13/14
of contactor K1
ok?
Change aux. contact
or contactor
No
No
