Rational SCC Line User Manual

-57-
S
S
C
C
SCC Diagnostic Mode
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1 - DIAGNOSTIC
Cabinet B1
130°C 345°C
act max“
- Temp. range: -30 - 340°C
(-22 - 644°F)
- 900°C (655°C until SW version
01-07-08) broken thermocouple
or loose plug
- to reset max value press RESET
4 - DIAGNOSTIC
Humidity B4
130°C 345°C
act max“
- Temp. range: -30 - 340°C
(-22 - 644°F)
- 900°C (655°C until SW version
01-07-08) broken thermocouple or
loose plug
- to reset max value press RESET
12 - DIAGNOSTIC
Temperature PCB
130°C 345°C
act max“
- Temp. range: -30 - 85°C (-22 -
185°F)
- to reset max value press RESET
(keep pressed until value is
re-seted)
- above 75°C (167°F) warning
on window #4 => clean air fi lter
- above 85°C (185°F) => Service 29
3 - DIAGNOSTIC
Not used
B3
900°C 900°C
B3 not used. No function
6 - 11 - DIAGNOSTIC
Core Temp B6 - B11
130°C 305°C
act max“
- Temp. range: -30 - 340°C (-22
- 644°F)
- 900°C (655°C until SW version
01-07-08) broken thermocouple
or loose plug
- to reset max value press RESET
14 - DIAGNOSTIC
Door Contact
S3
1 - 0
1 - door closed
0 - door open
2 - DIAGNOSTIC
Quenching B2
70°C 95°C
act max“
- Temp. range: -30 - 340°C (-22
- 644°F)
- 900°C (655°C until SW version
01-07-08) broken thermocouple or
loose plug
- to reset max value press RESET
5 - DIAGNOSTIC
Steam Generator B5
104°C 115°C
act max“
- Temp. range: -30 - 340°C (-22
- 644°F)
- 900°C (655°C until SW version
01-07-08) broken thermocouple or
loose plug
- to reset max value press RESET
13 - DIAGNOSTIC
Level Electrode S2
S2 1 - 0
Y1 0 - 1
S2 = 1 => Water level reached
S2 = 0 => Water level too low
Y1 = 0 => Filling solenoid not active
Y1 = 1 => Filling solenoid active
Reset
Reset
Reset
Reset Reset
Reset
Reset
