Rational SCC Line User Manual

-69-
S
S
C
C
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
2 - Function Test
Steam 100%
(Gas: see below)
0 - 1
Temperature B5 103°C
- Electric and gas units:
Steam heating 100%;
- Indication gas units (window 2):
„Steam Gas-Burner“
- Actual temperature of B5
Attention: Parts are not protected
against overload!
5 - Function Test
Fan motor top
Speed 3
1600rpm
actual speed
xxxx
Fan motor top:
- Select RPM with central dial
(default: second highest RPM):
- Typ 61: 500,1100,1550,1650
- Typ 62, 101, 201:
500,1250,1800,1900
- Typ 102, 202:
550,1450,2000,2200
8 - Function Test
SC Pump M4
1 - 0
Level electrode 1 - 0
- Activat. of SC Pump M4
- Level electrode shows 1 =
steam generator fi lled
- Level electrode shows 0 =
steam generator partial fi lled
3 - Function Test
Hot Air 50%
(Gas: see below)
0 - 1
Temperature B1 185°C
- Electric units: Hot air heating 50%;
- Gas units: Hot air heating 100%
- Indication window 2:
Table models: „Hot Air Gas-Burner“
Floor models: „Hot Air Gas-Top Burner“
- Actual temperature of B1
Attention: Parts are not protected
against overload!
6 - Function Test
Fan motor bottom
Speed 4
1900rpm
actual speed
xxxx
Fan motor bottom (only fl oor model):
- Select RPM with central dial
(default: second highest RPM):
- Typ 201:
500,1250,1800,1900
- Typ 202:
550,1450,2000,2200
9 - Function Test
Solenoid quenching Y2
1 - 0
Temperature B2 36°C
- Activation of solenoid valve
quenching Y2
- Indication of actual temperature B2
(needed for testing quenching
system).
1 - Function Test
Steam 50%
0 - 1
Temperature B5 103°C
- Electric units: Steam heating 50%;
- Gas units: not used
- Actual temperature of B5
Attention: Parts are not protected
against overload!
4 - Function Test
Hot Air 100%
(Gas: see below)
0 - 1
Temperature B1 185°C
- Electric units: Hot air heating 100%
- Only gas fl oor models:
Hot air heating 100%
Indication window 2:
„Hot Air Gas-Bottom Burner“
- Actual temperature of B1
Attention: Parts are not protected
against overload!
7 - Function Test
Solenoid valve fi llling Y1
1 - 0
Level electrode 1 - 0
- Activat. of solenoid valve fi llling Y1
- Level electrode shows 1 =
steam generator fi lled
- Level electrode shows 0 =
steam generator partial fi lled
Start
Start
Start
Start
Start
Start
Function test
Start
Start Start
