Adjusting speed of blower motor steam (+/ -10%)
(After blower speed adjustment the original rpm is shown in the temp. display, the
changed rpm is shown in the time display)
Press time key, keep it pressed and adjust displayed rpm with timer dial
SE9 = MIN rpm; SE10 = Start rpm; SE11 = MAX rpm
Always check CO
2
values of MAX rpm and MIN rpm in function test
Adjusting speed of blower motor hot air top (+/ -10%)
(After blower speed adjustment the original rpm is shown in the temp. display, the
changed rpm is shown in the time display)
Press time key, keep it pressed and adjust displayed rpm with timer dial
SE12 = MIN rpm; SE13 = Start rpm; SE14 = MAX rpm
Always check CO
2
values of MAX rpm and MIN rpm in function test
Adjusting speed of blower motor hot air bottom (+/ -10%)
(After blower speed adjustment the original rpm is shown in the temp. display, the
changed rpm is shown in the time display)
Press time key, keep it pressed and adjust displayed rpm with timer dial
SE15 = MIN rpm; SE16 = Start rpm; SE17 = MAX rpm
Always check CO
2
values of MAX rpm and MIN rpm in function test
SE 9,10,11
+
SE 12,13,14
+
SE 15,16,17
+
Notes:
Service Level: SE -- Basic settings
