Rational SCC Line User Manual

76-00050
0Version
MODUL 2 Heißluftheizung/Dampfheizung
Hot air heating/Steam heating
CM 101/102 G
1NAC230V 50-60Hz
Erstellt von
Created by
Datum
Date
Blatt
Page
PA
2
30.04.2004
1.08 / K1:14
1.08 / K1:A2
1.09 / PE
1.08 / K1:A1
BN
BU
YE/GN
RD
Gasgebläse (HL1) Gasblower
M8
1
M
~
N L1 PE
GND
U/min
PWM
W17
X60
11 22 33
W15
X51
33
44
22
W18
A5
Feuerungsautomat (HL1 und D)
Ignitionbox
BUSBUSPENL1
1
2
34
5
6
W17
W14
Gasventil Gas valve
Y12
X65
1 2 3
Elektrode Gasbrenner Electrode gas burner
B12
4
HL 1
RJ 45
Elektrode Gasbrenner Electrode gas burner
B11
RJ 45
Gasventil Gas valve
Y11
D
X52
33
44
22
W18
W15
Gasgebläse (D) Gasblower
M9
1
M
~
PWM
U/min
GND
N L1 PE
W17
X61
11 22 33
M5:~ / 5.00
M5:N / 5.00
PE / 5.00
A5/PCB / 5.01
A5/M1 / 5.01
0
0123456789
