Rational SCC Line User Manual

76-00050
0
Version
MODUL 5 Lüftermotor
Fan Motor, Cooling Fan
CM 101/102 G
1NAC230V 50-60Hz
Erstellt von
Created by
Datum
Date
Blatt
Page
PA
5
30.04.2004
1.09 / K1:1
1.09 / K1:3
2.08 / PE
2.08 / M5:~
2.08 / M5:N
2.08 / A5/M1
2.08 / A5/PCB
BK
BU
GN/YE
BN
BU
M11
Kühllüfter Cooling fan
M
1
~
A2 A1
M5
Kühllüfter Cooling fan
M
1
~
A2 A1
Lüftermotor Fan motor
M1
M
~
.
RJ 45
.
F20
6,3A
.
F21
6,3A
.
33
22
X22
11
A4 PCB
.
RJ 45
0
9
8
7
65
4
3
21
0
Blinkcode Lüftermotor
Siehe Trainingshandbuch Seite 83
Blink code fam motor
See Training manual page 83
