C
M
Mode: Hot Air
Temp. range
30-300°C (86-572°F)
Function Step
Select Hot Air
(Temp. 30-300°C (86-572°F))
Select time or core temperature
Close cabinet door
Timer starts at once
Hot Air supply until set temperature
inside cabinet is reached
Quenching (set to 90°C/194°F)
Responsible sensor
Reed switch S3
Logic on PCB
Cabinet sensor B1
Quenching sensor B2
Signal
Door open: 12VDC X27:(1-2)
Door closed: 0VDC X27:(1-2)
SSR active: 12VDC X24:(7-8)+(3-4)
SSR not act.: 0VDC X24:(7-8)+(3-4)
B2 above set Temp.: Y2 active
B2 below set Temp.: Y2 not active
Remark
Blinking dot in timer display
Y2 active: 230VAC, X19:(2-4)
Y2 not act.: 0VAC, X19:(2-4)
1
2
3
4
5
6
Note:
Below 100°C (212°F) fan at lowest speed when no energy required for longer than 2 minutes.
