CHAPTER
9
Manual No. 016-0171-148 149
C hapter 9
Using AccuBoom™
Introduction
AccuBoom is an automatic boom or implement section control feature that can be used in conjunction with the
Envizio Pro or Envizio Pro II field computers. The AccuBoom feature allows the field computer to automatically
control boom or implement sections by referencing the as-applied or coverage map. When AccuBoom detects
a section entering an area where a product has previously been applied, AccuBoom will automatically turn that
section Off. When the section leaves the previously applied area, AccuBoom automatically turns the section
back On.
Note: Prior to using the AccuBoom feature with the Envizio Pro or Envizio Pro II, the supporting
hardware components must be purchased and installed for the specific machine. Contact a local
Raven dealer for more information.
CAN Switch Box
If a Raven CAN Switch Box is installed with the field computer, the section switches must be in the ‘Accu’
position to allow AccuBoom control over the assigned sections. If the section switches are in the ‘On’ or ‘Off’
position, the AccuBoom system will treat the section as overridden and will not automatically turn the section
on or off based on previous application areas or field boundaries.
Note: The CAN Switch Box must be used as the primary control interface for section, master or product
control status.
Make sure to toggle the master switch to the off position when closing or exiting a job to
avoid unintentional product application once the field computer or control console closes
application management functions. It is also good practice to shut off product and section
switches when the application system is not being used.
