Chapter 2
10 Envizio Pro and Envizio Pro II Installation and Operation Manual
Amp Connector Pin Definitions
Main Amp Connector Auxiliary Amp Connector
1.
Battery Negative
1.
DGPS Transmit
(Corrections In)
2.
Ext. Switch
3.
CAN Hi
2.
Ext. Switch
4.
CAN Lo
3.
CAN Hi
5.
DGPS Receive
4.
CAN Lo
6.
DGPS Transmit
5.
DGPS Receive
(To External Devices)
7.
DGPS CTS
8.
DGPS RTS
6.
DGPS Transmit
(To External Devices)
9.
Console Transmit
10.
Console Receive
7.
Auxiliary Receive
11.
RS232 Ground
8.
Auxiliary Transmit
12.
Console CTS
9.
Auxiliary CTS
13.
Console RTS
10.
DGPS Receive
(Corrections In)
14.
+ 12 V Ignition
15.
+ 12 V Switched
11.
Auxiliary RTS
16.
Battery Positive
12.
RS232 Ground
13.
Not Used
14.
Radar Out
Auxiliary Amp
Connection
Main Amp
Connection
