APPENDIX
F
Manual No. 016-0171-148 203
A ppend ix F
Reference of Icons
Navigation
The following icons will be used to navigate within the menu screens and to edit and save settings.
Touch the Home icon when it appears to return to the Home screen. Any active jobs will continue
in the background. Note that some Tools Menus will not be accessible while a job is in progress.
Touch the Accept icon to confirm any changes to a screen. Touching the Accept icon will save
those settings and proceed to the next screen.
Touch the Cancel icon to exit the screen without saving any changes made on a screen. If the
Cancel icon is displayed in grey, the cancel feature is not available.
Like the Accept icon, the Next icon accepts changes and proceeds to the next screen in a setup
procedure. Touch this icon where it appears to access more settings or to continue a setup
procedure. The last screen in a setup procedure should display the Accept icon.
Touch the Previous icon to return to the last screen displayed during a setup procedure or wizard.
The Up icon, where it appears, increases displayed values in preset increments. Touch this icon to
increase a value until the desired value is displayed.
The Down icon, where it appears, decreases displayed values in preset increments. Touch this
icon to decrease a value until the desired value is displayed.
Touch the Create New icon when it appears to create and rename new job related files.
Note: Names of jobs, vehicle profiles, guidance lines or boundary maps stored on the field computer
cannot begin or end with a space.
