6
Manual No. 016-0171-148 69
Basic Operation
3. The In Job Nudge Settings screen will be displayed.
4. The Nudge Settings screen displays the following options:
a. To apply nudge values to a guidance path, the ‘On-Screen Nudge Controls’ option must be Enabled.
b. Select the ‘Nudge 1’ or ‘Nudge 2’ radio buttons to select the user defined nudge to apply when the on-
screen nudge buttons are used.
c. Touch the Nudge 1 or Nudge 2 button and use the on-screen keypad to enter the desired values for
each nudge setting.
d. Touch the Reset Nudge button to remove any nudge values from the displayed guidance path.
e. Touch the green check mark to return to the Guidance screen. The On-Screen Nudge buttons will be
displayed next to the vehicle indicator.
Nudge
Left/Right
Active Nudge
Value
Total Nudge
applied to
displayed path
To Next Page
