7.6Autopilotstatussymbols

Theautopilotstatusisindicatedinthedatabar.

SymbolDescription

AutopilotisinStandbymode.

AutopilotisinTrackmode.

AutopilotisinAutomode.

Noautopilotdetected.

Autopilotalarmactive.

Dodgemodeisactive.

Fishmodeisactive.

SymbolDescription

Autopilotcalibration.

Powersteeringactive.

WindVanemodeisactive.

Usingautopilotcontrol

105
